Autodesk ReCap Pro (Reality Capture) is a specialized application designed to convert physical world data—captured via laser scanners (LiDAR) or photographs (photogrammetry)—into highly accurate, dense 3D point clouds or textured 3D meshes.

These digital assets can then be cleanly piped into standard design tools like Revit, Civil 3D, AutoCAD, and Navisworks for accurate as-built modeling and site coordination.

Key Features

The engine is primarily used to eliminate manual physical site measuring, giving AEC professionals real-world spatial environments to design within.

1. Advanced Scan-to-Mesh Workflows

• Localized Scan-to-Mesh: You can convert heavy 3D point cloud datasets into lightweight, segmented 3D mesh models directly via customized local processing. This eliminates the bottleneck of uploading massive gigabyte-scale datasets to the cloud just to compute a mesh.

• Unified Revit Integration: Features a dedicated plugin that allows you to easily import locally processed meshes directly into Autodesk Revit as Revit Families. This simplifies modeling complex existing geometries (like historical facades or exposed MEP piping) without manual rebuilding.

2. Laser Scan Processing & Registration

• Point Cloud Registration: Automatically pairs and links overlapping raw laser scans (from terrestrial scanners like Leica, Faro, or Riegl) into a singular, cohesive coordinate system using target-based or targetless registration.

• RealView Navigation: Provides a highly realistic, full panoramic photo view of the environment at each scanning station. You can switch fluidly between the absolute point cloud geometry and the visual real-world panorama to inspect site features, add text markups, or drop measurements.

• Intelligent Data Cleaning: Includes noise reduction filters and decimation grids to strip out unwanted artifacts (such as passing cars or pedestrian silhouettes moving through a scan field).

3. Integrated Photogrammetry (ReCap Photo)

• Photo-to-3D Reconstruction: Includes built-in access to ReCap Photo, a specialized sub-application designed to stitch drone or handheld digital photographs into survey-grade 3D meshes, ortho-rectified aerial imagery, and elevation maps using GPS spatial tag coordinates.

• ESRI Basemap Integration: Features native integration of ESRI Basemaps in the Ground Control Point (GCP) editor map view, helping surveyors seamlessly verify coordinates against up-to-date geographical context.

4. Cloud-Based Viewer & Extraction Tools

• ACC ReCap Viewer: Integrated directly with the Autodesk Construction Cloud (ACC) and Autodesk Docs. Large datasets can be visualized, annotated, and shared directly through a web browser, minimizing the need to download heavy point cloud structures onto local office hardware.

• Geometrical Feature Extraction: Allows users utilizing the cloud browser viewer to automatically recognize and extract precise 3D geometries, linear features, and architectural structures (such as ADA-compliant ramps or curb alignments).

System Requirements

Because ReCap Pro processes massive point clouds containing hundreds of millions of spatial points, your computer’s hardware capacity (particularly RAM and processing cores) heavily dictates file indexing and meshing speeds.

1. Autodesk ReCap Pro (Desktop Point Cloud Application)
